Features
l High strength yarn member;
l High quality tight buffered/ loose tube;
l Various yarn and jacket materials optional
Features
l High strength yarn member;
l High quality tight buffered/ loose tube;
l Various yarn and jacket materials optional.
Specifications
|
Core number |
24 |
48 |
72 |
96 |
144 |
|
|
Outer Diameter (mm) |
4.2±0.3*7.6±0.4 |
9.0±0.5 |
11.2±0.5 |
13.5±0.5 |
17.5±0.5 |
|
|
Weight (kg/km) |
31 |
79 |
126 |
178 |
285 |
|
|
Max.
tensile Strength (N) |
Short-term |
300 |
600 |
1000 |
1000 |
1000 |
|
Long-term |
160 |
200 |
300 |
300 |
300 |
|
|
Max. Crush Resistance (N/100mm2) |
Short-term |
1000 |
1000 |
1000 |
1000 |
1000 |
|
Long-term |
300 |
300 |
300 |
300 |
300 |
|
Note：1.Different materials
and cable structures could be customized;
2.
Specifications are subject to change due to different material and structure.
