Features
l High strength yarn member;
l High quality tight buffered/ loose tube;
l 4C ~ 24Cfiber optional;
l Various yarn and jacket materials optional.
Features
l High strength yarn member;
l High quality tight buffered/ loose tube;
l 4C ~ 24Cfiber optional;
l Various yarn and jacket materials optional.
Specifications
|
Core number |
12 |
24 |
|
|
Outer Diameter (mm) |
3.0±0.15 |
3.8±0.2 |
|
|
Weight (kg/km) |
4.8 |
6.5 |
|
|
Max.
tensile Strength (N) |
Short-term |
100 |
150 |
|
Long-term |
30 |
50 |
|
|
Min.
Bending Radius (mm) |
Dynamic |
20D |
20D |
|
Static |
10D |
10D |
|
|
Max. Crush Resistance (N/100mm2) |
500 |
1000 |
|
Note：1.Different materials
and cable structures could be customized;
2.
Specifications are subject to change due to different material and structure.
