Features
● Operating Data Rate up to 2.5bps
● Single 3.3V Power Supply and TTL Logic Interface
● Class 1 FDA and IEC60825-1 Laser Safety Compliant
● Compliant with SFP MSA Specification
● Operating Temperature Range: 0 ~+70℃
APPLICATIONS
● Gigabit Ethernet
● Fiber Channel
● Other Optical Links
FEATURES
● Operating Data Rate up to 2.5bps
● Single 3.3V Power Supply and TTL Logic Interface
● Class 1 FDA and IEC60825-1 Laser Safety Compliant
● Compliant with SFP MSA Specification
● Operating Temperature Range: 0 ~+70℃
Ordering Information:
|
Part No. |
Data Rate |
Wavelength |
Distance |
Operating Temp. |
Tx Power |
Rx Sensitivity |
|
LJ-180 |
10/100/1G |
RJ45,CAT5 |
100m |
-40~85℃ |
- |
- |
|
LJ-181 |
1.25G |
RJ45,CAT5 |
100m |
-40~85℃ |
- |
- |
|
LS1-500 |
1.25G |
850nm VCSEL |
550m |
0~70℃ |
-8~ -4 |
-18 |
|
LS1-100 |
1.25G |
1310nm FP |
15Km |
0~70℃ |
-9~ -3 |
-20 |
|
LS1-180 |
1.25G |
1310nm FP |
15Km |
-40~85℃ |
-9~ -3 |
-20 |
|
LS1-220 |
1.25G |
TX1310/RX1490 |
20Km |
0~70℃ |
-9~ -3 |
-22 |
|
LS1-221 |
1.25G |
TX1490/RX1310 |
20Km |
0~70℃ |
-9~ -3 |
-22 |
|
LS1-400 |
1.25G |
1310nm DFB |
40Km |
0~70℃ |
-2~ +3 |
-23 |
|
LS1-401 |
1.25G |
1550nm DFB |
40Km |
0~70℃ |
-4~ +1 |
-20 |
|
LS1-800 |
1.25G |
1550nm DFB |
80Km |
0~70℃ |
-2~ +3 |
-23 |
|
LS1-990 |
1.25G |
1550nm DFB+APD |
120Km |
0~70℃ |
0~ +3 |
-31 |
|
LS2-100 |
2.5G |
1310nm FP |
2Km |
0~70℃ |
-9~ -3 |
-18 |
|
LS2-101 |
2.5G |
1310nm DFB |
15Km |
0~70℃ |
-5~ 0 |
-18 |
|
LS2-181 |
2.5G |
1310nm DFB |
15Km |
-40~85℃ |
-5~ 0 |
-18 |
|
LS2-400 |
2.5G |
1310nm DFB+APD |
40Km |
0~70℃ |
-2~ +3 |
-27 |
|
LS2-800 |
2.5G |
1550nm DFB+APD |
80Km |
0~70℃ |
-2~ +3 |
-28 |
