FEATURES
● Operating optical data rate up to 112Gbps
● Operating electrical serial data rate up to 27.952493Gbps
● 4 parallel electrical serial interface
● Transmission distance up to 10Km
● 1310 nm window cooled EA-DFB LD
● MDIO Communication Interface
● Compliant with IEEE 802.3ba
● Compliant with CFP2 MSA
Applications
● OTN-OTU4
● Switch to switch/router interface
● P to P Access Network
Features
● Single +3.3V power supply
● Operating optical data rate up to 112Gbps
● Operating electrical serial data rate up to 27.952493Gbps
● 4 parallel electrical serial interfaces
● Transmission distance up to 10Km
● 1310 nm window cooled EA-DFB LD
● Low-power consumption (Max:6W)
● Operating temperature: 0 ~ 70℃
● Compliant with ROHS
● MDIO Communication Interface
● Compliant with IEEE 802.3ba
● Compliant with CFP2 MSA
Ordering Information:
|
Part No. |
Description |
Data Rate |
Distance |
Power Consumption |
Tx Power |
Rx OMA Sensitivity |
Note |
|
LC2-100 |
CFP2 LR4 |
100Gbps |
10Km |
＜6W |
-2.9~ +4.5 |
-8.6 |
LAN-WDM EML |
|
LC2-101 |
CFP2 RX4 |
100Gbps |
-- |
＜4W |
-- |
-8.6 |
RX ONLY |
|
LC2-102 |
CFP2 LR4 |
100Gbps |
10Km |
＜5W |
-2~ +4 |
-8.6 |
LAN-WDM DML |
|
LC2-201 |
CFP2 RX4 |
100Gbps |
20Km |
＜5W |
-- |
-- |
APD RX ONLY |
|
LC2-400 |
CFP2 ER4 |
100Gbps |
40Km |
-- |
-- |
-- |
EML+SOA+PIN |
