Features
● 4 Parallel lanes design (SR4, eSR4, PSM LR4, PSM IR4)
● 4 CWDM lanes Mux design (LR4, IR4, ER4)
● Compliant with QSFP+MSA Specification
● Low power design
● Operating Temperature: 0~70℃
Applications
● InfiniBand
● 40G Ethernet
● Data center, sever and Super computer
Features
● 4 Parallel lanes design (SR4, eSR4, PSM LR4, PSM IR4)
● 4 CWDM lanes Mux design (LR4, IR4, ER4)
● Compliant with QSFP+MSA Specification
● Low power design
● Operating Temperature: 0~70℃
Ordering Information
|
Part No. |
Description |
Data Rate |
Wavelength |
Distance |
Power Consumption |
Tx Power |
Rx OMA Sensitivity |
Connector
&Fiber |
|
LQ-500 |
QSFP+SR4 |
40Gbps |
850nm VCSEL |
100m |
＜1.5W |
-7.6~ +1 |
-9.5 |
MPO/MMF |
|
LQ-501 |
QSFP+eSR4 |
40Gbps |
850nm VCSEL |
300m |
＜1.5W |
-7.3~ +1 |
-9.9 |
MPO/MMF |
|
LQ-100 |
QSFP+LR4 Lite |
40Gbps |
DFB CWDM |
2Km |
＜3.5W |
-7~ +2.3 |
-11.7 |
LC/SMF |
|
LQ-101 |
QSFP+LR4 |
40Gbps |
DFB CWDM |
10Km |
＜3.5W |
-7~ +2.3 |
-13.7 |
LC/SMF |
|
LQ-900 |
QSFP+PSM IR4 |
40Gbps |
1310nm FP |
1.4Km |
＜3.5W |
-5.5~ +1.5 |
-11.5 |
MPO/MMF |
|
LQ-901 |
QSFP+PSM LR4 |
40Gbps |
1310nm DFB |
10Km |
＜3.5W |
-5.5~ +1.5 |
-12.6 |
MPO/MMF |
